ICS Monitoring – SDRN control

SPECTRUM MONITORING SOLUTIONS FOR SPECTRUM REGULATORS

FLEXIBLE & SCALABLE

CAPABLE OF MANAGING MULTIPLE MEASUREMENTS

AUTOMATIC POST-PROCESSING OF REAL-TIME DATA

MONITORING EMISSIONS, SPECTRUM USAGE ASSESSMENT AND CONTROL OF LICENSED EMISSIONS. INDEPENDENT OF MEASUREMENT EQUIPMENT

SDRN control is part of ATDI Spectrum Management System. it performs tasks in accordance with radio regulations and verifies compliance with the frequency allocation conditions, the frequency usage and channel occupancy, generates interference case studies and searches for unauthorised emissions.

SDRN control FEATURES:

Full and real-time integration with licensed equipment database
Automated storage of electromagnetic situation measurements and analysis data
Establishes spectrum reference situation based on measurement results and propagation modelling
Real-time spectrum analysis without interruption from measurements already launched
Background mode measurements require no human intervention

Integrated GIS (map layers and terrain data)

Spectrum Occupancy measurements
Detection of unauthorised emissions
Licensed transmitter data collection and storage
Compares spectrum emissions with spectrum masks from authorised transmitters
Compares spectrum emissions with reference spectrum masks
Bandwidth measurements
Frequency band scanning
Localisation of unauthorised emissions

Hybrid localisation (TDOA / AOA / POA / RSSI)
HOMING (Machine learning algorithm – HTZ required)

SDRN control MODULES

Server modules:
SDRN controls (sdrn cs) – versions available for single and cluster
Application server
Centralised data processing
Supports measurement management services
Analysis of monitoring results sdrn control server aggregation (sdrn csa)
Software module for load balancing point into cluster sdrn control server infocenter (sdrn csi)
Software module for high performance data access between different sources within cluster sdrn control server calculation (sdrn csc)
Software module for high performance massive computing by propagation models.



End point modules:
SDRN controlU (sdrn cu) – software module for the management of spectrum monitoring hardware through user interface
SDRN controlA (sdrn ca) – software module for management of spectrum monitoring hardware in automated mode
SDRN control API (sdrn API) – software module to interface with third party software
SDRN control plug-in for ICS manager



SOA ARCHITECTURE

PHYSICAL ARCHITECTURE

SDRN control PERFORMANCE

SDRN control features a high performance multi-task engine on different levels:

Application level: user tasks through a friendly interface, which is not structured or scheduled
Logical level: FFT
Measurement level: conveys command structure in time, frequency plan and priority



SDRN control SENSORS

SDRN control is compatible with:

  • Spectrum analysers: Rohde & Schwarz (FSW, FSVx, FSVAx, ESRPx, FPH, FSH4/8, ZVH), Keysight Technologies (N99xx series), Anritsu (MS27xx series), Signal Hound (BB60C)
  • Measuring receivers: Rohde & Schwarz (EM100, PR100, DDFxxx, EBD, ESMD, EB5xx)
  • Modulation analysers: Rohde & Schwarz (ETL)
  • Cellular communication network analysers: Rohde & Schwarz (TSMW, TSME, TSMA)
  • Devices for broadband access network identification (protocols 802.11хх and their modifications) WR61
  • Remote control: Rohde & Schwarz ROMES

SDRN control provides easy integration with any new measurement equipment from an API via SDRN control, including third- party software.

SDRN control CONFIGURATION

The typical confirmation for Spectrum Surveillance:

HARDWARE:
Spectrum Analyser SH BB60C
GPS
Computer iROBO-3000A
OS Winpro 10 SNGL OLP NL
Power supply Eaton Ellipse Eco
Weather protection
Antenna AOR DA 3200
Lightning Rod PR-722Q
Switch ethernet RB60IGS MIkrotik
Cables

DATA RECEIVED:
Radio spectrum (up to 24 GHz/s)
IQ stream with PPS marks (up to 40 MS/s)

FREQUENCY BAND:

Antenna 300 MHz – 3 GHz
Receiver 9 kHZ – 6 GHz



HARDWARE:
Spectrum analyser R&S®FPL1000
GPS
Computer iROBO-3000a
OS WinPro 10 SNGL OLP NL
Power Supply Eaton Ellipse ECO
Weather protection
Antenna UHF VH08-ANT-0861
Lightning rod Pr-722Q
Switch EtherNet RB60IGS Mikrotik
Cables

DATA RECEIVED:

Radio spectrum (up to 24 GHz/s)
IQ stream with PPS marks (up to 60 MS/s)

FREQUENCY BAND:

Antenna 300 MHz – 3 GHz
Receiver 9 kHz – 6 GHz





SDRN control logical and physical architecture:

Sensor network server:
Raw data collection and storage
Data aggregation
Mission planning

Server for Spectrum Monitoring:
SDRN control
Analysis of spectrum monitoring data

Spectrum Management and Engineering:
ICS manager
HTZ communications / HTZ warfare



SDRN CASE STUDY

PHASE I

SEPTEMBER 2019:

  • Area: Kiev (Ukraine) left bank (70 km²)
  • Number of sensors: 10
  • Sensors: Signal Hound SH BB60C
  • Sensor network server: application server (2 E5 7000, 4 processors 4 cores, 512 GB RAM, 1 TB HDD) with 2 virtual machines:
    • Aggregation server
    • Databus server
  • Database server (2 E5 7000 4 processors 4 cores, 1 TB RAM, 10 TB HDD)
  • Data received – Sensor network: 3 GB / day
  • Data stored after processing: 3 MB / day
  • Transport bit rate: 100 Mbps: 10% load
PHASE II

JANUARY 2020:

  • Areas: KYIV City (Ukraine) 900 km², BORISPOL City and Airport (25 km²), LVIV City (200 km²)
  • Sensors: 70 + 5 + 25 (100)
  • Sensor type: Rohde & Schwarz FPL 1007
  • Sensor network server: applications server (2 E5 7000, 4 processors 4 cores, 512 GB RAM, 1 TB HDD) with 2 virtual machines:
    • Aggregation server
    • Databus server
  • Database server (2 E5 7000 4 processors 4 cores, 1 TB RAM, 10 TB HDD)
  • Data received – Sensor network: 300 GB / day
  • Data stored after processing: 1 GB / day
  • Transport bit rate: 100 Mbps: 70% load
PHASE III

SEPTEMBER 2020:

  • Areas: 25 regional centers
  • Sensors: 300 – 400
  • Hybrid localization (POA/TDOA/AOA)
